Description:
Our company, China Shuguang Graphite Co., Ltd. Locates, is one of the biggest enterprises of the mineral, chosen the mineral and further processed in whole from China. Our products, like carbon raschig ring, graphite raschig ring are widely used in the fields of petroleum & chemical industry, refining, electric power, metallurgy, machinery, papermaking, automobile, shipping building, pharmacy, aerospace industry, nuclear industry, etc. We rely on advanced technology and management system, superior production equipments and test instruments, high quality products and first-class service. The products, graphite raschig rings, graphite raschig rings, raschig ring, carbon ring, graphite ring enjoy the high reputation in domestic and abroad market, and it has been exported to more than 20 countries and regions.
The graphite raschig rings we offer are with corrosion resistance, thermal shock resistance, and high temperature stability, which can benefit derived for tower packing.
Features:
1. Low coefficient of thermal expansion, resists damage caused by severe shocks.
2. May be used in most acids, alkalies and solvents.
3. Light weight and high mechanical strength with no soluble bond.

4. Long life packing with high temperature operating capabilities. Used in chlorine-hydrochloric mixtures and phosphoric acid.
Carbon Raschig Ring

Graphite Raschig Ring

Specifications:

  SIZE   DENSITY SURFACE AREA Void Thickness
part# OD (in.) OD (mm) lbs/ft3 kg/m3 ft2/ft3 m2/m3 % mm in.
CRR-1/2 0.5 13 30 474 117 384 71 1.75 1/16
CRR-3/4  0.75 19 34 546 75 244 61 4.24 5/32
CRR-1.0 1.0 25 34 546 57 185 62 5.46 7/32
CRR-1.5 1.5 38 34 546 38 124 60 8.43 11/32
CRR-2.0 2.0 50 27 433 29 91 71 7.14 9/32
CRR-3.0 3.0 75 23 369 19 62 78 8.63 11/32

Other size is also available on request.

We are professional manufacturer and supplier of carbon graphite raschig ring in china. We have become a leading producer of carbon graphite products on the Chinese market over the past 30 years' experience. Our company has already passed the International Quality System Certification known as ISO9001:2000. We can manufacture the products according to the clients' demands and willing to offer you OEM service (original equipment manufacture).
